R11 Manual Reset Relay

The K-Dyne, Inc. Model R11 pneumatic relay is a compact manually operated instrument valve that is well suited for the rigors of inland and offshore production control systems. It operates as easy as a 3-way normally closed, manual reset pneumatic valve with a detent (BYPASS) feature. Its construction makes it ideal for field mounting on actuators, pressure sensors or other control devices.

Manual Reset Relay

Download Cut Sheet

Special Features

Compact size saves space in panel use

aSeals may be maintained without removal of instrumentation connections

bPanel mountable using optional nut (not included with this unit)

sdsaEasily converted to indicating relay in the shop or field

sdsaField proven materials of construction

sdsaLatch closed design prevents pilot signal from opening relay

sdsaDetent pin for temporary "BYPASS"
